Smooth Urethane Round Belting 30m/roll Reinforced Abrasion Resistance

Chiny Wuxi Jiunai Polyurethane Products Co., Ltd Certyfikaty
Chiny Wuxi Jiunai Polyurethane Products Co., Ltd Certyfikaty
Customer satisfaction products , good service !

—— Mr. Alcioni possamai

we are very impressed with the quality of the belts you produced.

—— Mr.Mike

your products are very popular in my markets.

—— Mr. jone

Im Online Czat teraz

Smooth Urethane Round Belting 30m/roll Reinforced Abrasion Resistance

Smooth Urethane Round Belting 30m/roll Reinforced Abrasion Resistance
Smooth Urethane Round Belting 30m/roll Reinforced Abrasion Resistance Smooth Urethane Round Belting 30m/roll Reinforced Abrasion Resistance Smooth Urethane Round Belting 30m/roll Reinforced Abrasion Resistance Smooth Urethane Round Belting 30m/roll Reinforced Abrasion Resistance

Duży Obraz :  Smooth Urethane Round Belting 30m/roll Reinforced Abrasion Resistance

Szczegóły Produktu:
Place of Origin: China
Nazwa handlowa: jiuna
Orzecznictwo: ROHS
Model Number: Diameter 3mm~20mm
Zapłata:
Minimum Order Quantity: 5 rolls
Packaging Details: Inner packing is plastic film .outer packing is carton .
Delivery Time: Within 5 working days After receipt of your deposit
Payment Terms: T/T, 50% payment in advance ,50% balance before shipment ; Western Union ; L/C
Supply Ability: 96.000 meters per Month
Szczegółowy opis produktu
stretching rate: 1.5%-3% color: red
material: PU longth: 300m/roll 200m/roll 100m/roll 50m/roll 30m/roll
hardness: 85A-90A type: PU smooth round belt
High Light:

pu extruded belt

,

green round belt

Smooth Urethane Round Belting 300m/roll Reinforced Abrasion Resistance
(1)Thermoplastic polyurethane material, easy to be melted jointed
(2)Reinforced by Polyester Cord or Steel Cord
(3)Temperature range -35°C - 80°C
(4)Shore A hardness range 80A - 98A
(5)With excellent resistance to flex, abrasion resistance, easy jointed and other characteristics. Widely used in textile, packaging, printing, machinery, electronic, glass, chemicals, ceramics and other industries, especially in the ceramic industry, widely used in the facilities line the glaze, polishing lines, and transmission line.
(6)Round Belt:
Round Belt Dia. is from 2mm to 30mm
Smooth Belt with good surface finish; Rough belt with even surface roughness. They are used widely.


Transmission purposes of textile machines, packaging machines, printing presses, food machinery, industrial and paper equipments. Cut round belts can be joined as the endless belts as required according to the drive wheel distance and pulley size.

Features:
Outstanding abrasion resistance
High tensile and tear strength
Resistance to oils, fuels,and oxygen
Good weatherability and high impact resistance
Low compression set

Application:
Newspaper conveying,
Packing machines,
Ceramic and stoneware processing plants,
Floor and roof tiles conveying,
Wood Working machineries,
Textile machines,
Paper industry machines,
Food grading machines, other food processing machines.



Items NO.Φ

Least radius of gyration

Stretching rate

Maximum tensile rate

Hardness

Length of rolled

DIA(mm)

 In

mm

  %

Kg

Lbs

Shore( A)

Length of rolled
 ( m )

2mm

0.79

20

1.5-3%

0.3

0.7

95

400

2.5mm

0.87

22

1.5-3%

0.4

0.9

95

400

3mm

0.98

25

1.5-3%

0.7

1.6

90

400

3.5mm

1.18

30

1.5-3%

0.95

2.1

90

400

4mm

1.38

35

1.5-3%

1.2

2.7

90

200

5mm

1.57

40

1.5-3%

2.0

4.3

90

100

6mm

1.97

50

1.5-3%

3.2

7.0

90

100

7mm

2.17

55

1.5-3%

4.1

9.0

90

100

8mm

2.56

65

1.5-3%

5.0

11.0

90

100

9mm

2.95

75

1.5-3%

6.8

15.0

90

50

10mm

2.95

75

1.5-3%

7.7

17.0

90

50

12mm

3.94

100

1.5-3%

12.2

27.0

90

30

15mm

4.72

120

1.5-3%

17.7

39.0

90

30

18mm

5.71

145

1.5-3%

25.4

56.0

90

30

20mm

6.30

160

1.5-3%

31.3

69.0

90

30


Smooth Urethane Round Belting 30m/roll Reinforced Abrasion Resistance 0Smooth Urethane Round Belting 30m/roll Reinforced Abrasion Resistance 1Smooth Urethane Round Belting 30m/roll Reinforced Abrasion Resistance 2
