5mm PU Belt Transmission Urethane Belting Good Resistance To Fuel

Chiny Wuxi Jiunai Polyurethane Products Co., Ltd Certyfikaty
Chiny Wuxi Jiunai Polyurethane Products Co., Ltd Certyfikaty
Customer satisfaction products , good service !

—— Mr. Alcioni possamai

we are very impressed with the quality of the belts you produced.

—— Mr.Mike

your products are very popular in my markets.

—— Mr. jone

Im Online Czat teraz

5mm PU Belt Transmission Urethane Belting Good Resistance To Fuel

5mm PU Belt Transmission Urethane Belting Good Resistance To Fuel
5mm PU Belt Transmission Urethane Belting Good Resistance To Fuel 5mm PU Belt Transmission Urethane Belting Good Resistance To Fuel 5mm PU Belt Transmission Urethane Belting Good Resistance To Fuel 5mm PU Belt Transmission Urethane Belting Good Resistance To Fuel

Duży Obraz :  5mm PU Belt Transmission Urethane Belting Good Resistance To Fuel

Szczegóły Produktu:
Place of Origin: China
Nazwa handlowa: Jiuna
Orzecznictwo: ROHS
Model Number: Diameter5 mm
Zapłata:
Minimum Order Quantity: 1000 meters
Packaging Details: Inner packing is plastic film .outer packing is carton
Delivery Time: Within 5 working days After receipt of your deposit
Payment Terms: T/T, 50% payment in advance ,50% balance before shipment ; Western Union ; L/C
Supply Ability: 96.000 meters per Month
Szczegółowy opis produktu
materiał: PU rodzaj: Okrągły pasek z PU
color: orange zastosowanie temperatury: -35 ℃ ~ 100 ℃
powierzchnia: gładki Twardość: 85A-90A
długość: 30m/rolka
High Light:

okrągły pasek pu

,

zielony okrągły pasek

,

okrągły pasek poliuretanowy o średnicy 5 mm



5mm PU Belt Transmission Urethane Belting Good Resistance To Fuel

Items NO.Φ

Least radius of gyration

Stretching rate

Maximum tensile rate

Hardness

Length of rolled

DIA(mm)

 In

mm

  %

Kg

Lbs

Shore( A)

Length of rolled

2mm

0.79

20

1.5-3%

0.3

0.7

95

400

2.5mm

0.87

22

1.5-3%

0.4

0.9

95

400

3mm

0.98

25

1.5-3%

0.7

1.6

90

400

3.5mm

1.18

30

1.5-3%

0.95

2.1

90

400

4mm

1.38

35

1.5-3%

1.2

2.7

90

200

5mm

1.57

40

1.5-3%

2.0

4.3

90

100

6mm

1.97

50

1.5-3%

3.2

7.0

90

100

7mm

2.17

55

1.5-3%

4.1

9.0

90

100

8mm

2.56

65

1.5-3%

5.0

11.0

90

100

9mm

2.95

75

1.5-3%

6.8

15.0

90

50

10mm

2.95

75

1.5-3%

7.7

17.0

90

50

12mm

3.94

100

1.5-3%

12.2

27.0

90

30

15mm

4.72

120

1.5-3%

17.7

39.0

90

30

18mm

5.71

145

1.5-3%

25.4

56.0

90

30

20mm

6.30

160

1.5-3%

31.3

69.0

90

30



Details:



(1)Thermoplastic polyurethane material, easy to be melted jointed

(2)Reinforced by Polyester Cord or Steel Cord

(3)Temperature range -35°C - 80°C

(4)Shore A hardness range 80A - 98A

(5)With excellent resistance to flex, abrasion resistance, easy jointed and other characteristics.

Widely used in textile, packaging, printing, machinery, electronic, glass, chemicals, ceramics and

other industries, especially in the ceramic industry, widely used in the facilities line the glaze,

 polishing lines, and transmission line.

(6)Round Belt:

Round Belt Dia. is from 2mm to 30mm

Features:

Outstanding abrasion resistance
High tensile and tear strength
Resistance to oils, fuels,and oxygen
Good weatherability and high impact resistance
Low compression set

Application:

Newspaper conveying,
Packing machines,
Ceramic and stoneware processing plants,
Floor and roof tiles conveying,
Wood Working machineries,
Textile machines,
Paper industry machines,
Food grading machines, other food processing machines.
