Tensile Strength Polyurethane Round Belt / Green PU Extruded Belt

Chiny Wuxi Jiunai Polyurethane Products Co., Ltd Certyfikaty
Chiny Wuxi Jiunai Polyurethane Products Co., Ltd Certyfikaty
Customer satisfaction products , good service !

—— Mr. Alcioni possamai

we are very impressed with the quality of the belts you produced.

—— Mr.Mike

your products are very popular in my markets.

—— Mr. jone

Im Online Czat teraz

Tensile Strength Polyurethane Round Belt / Green PU Extruded Belt

Tensile Strength Polyurethane Round Belt / Green PU Extruded Belt
Tensile Strength Polyurethane Round Belt / Green PU Extruded Belt Tensile Strength Polyurethane Round Belt / Green PU Extruded Belt Tensile Strength Polyurethane Round Belt / Green PU Extruded Belt Tensile Strength Polyurethane Round Belt / Green PU Extruded Belt

Duży Obraz :  Tensile Strength Polyurethane Round Belt / Green PU Extruded Belt

Szczegóły Produktu:
Place of Origin: China
Nazwa handlowa: jiuna
Orzecznictwo: ROHS
Model Number: Diameter 5mm~15mm
Zapłata:
Minimum Order Quantity: 10rolls
Packaging Details: Inner packing is plastic film .outer packing is carton .
Delivery Time: Within 5 working days After receipt of your deposit
Payment Terms: T/T, 50% payment in advance ,50% balance before shipment ; Western Union ; L/C
Supply Ability: 96.000 meters per Month
Szczegółowy opis produktu
color: green material: PU
longth: 300m/roll 200m/roll 100m/roll hardness: 85A-90A
tensile rate: 0.3kg-31.3kg stretching rate: 1.5%-3%
High Light:

pu extruded belt

,

green round belt

Tensile Strength Polyurethane Round Belt / Green PU Extruded Belt

Detailed Product Description:

PU Cord Belt Application :

Application:

Newspaper conveying,
Packing machines,
Ceramic and stoneware processing plants,
Floor and roof tiles conveying,
Wood Working machineries,
Textile machines,
Paper industry machines,
Food grading machines, other food processing machines.

PU Cord Properties :

-Excellent abrasion resistance.

-Good resistance to fuel , oils and oxygen.

-Contains no plasticizer.

-Wide application temperature from -30℃~+80℃

transmission Round Belting Feature :

Features:

Outstanding abrasion resistance
High tensile and tear strength
Resistance to oils, fuels,and oxygen
Good weatherability and high impact resistance
Low compression set



Items No. φ least radius of gyration stretch rate Maximum tensile rate Hardness length of rolled

DIA

(mm)

In mm Stretching rate Kg Lbs

Hardness

(A)

Roll

(m)

2mm 0.79 20mm 1.5-3% 0.3 0.7 90 400
3mm 0.98 25mm 1.5-3% 0.7 1.6 90 400
4mm 1.38 35mm 1.5-3% 1.2 2.7 85 200
5mm 1.57 40mm 1.5-3% 2.0 4.3 85 100
6mm 1.97 50mm 1.5-3% 3.2 7.0 85 100
7mm 2.17 55mm 1.5-3% 4.1 9.0 85 100
8mm 2.56 65mm 1.5-3% 5.0 11.0 85 100
9mm 2.95 75mm 1.5-3% 6.8 15.0 85 50
10mm 2.95 75mm 1.5-3% 7.7 17.0 85 50
12mm 3.94 100mm 1.5-3% 12.2 27.0 85 30
15mm 4.72 120mm 1.5-3% 17.7 39.0 85 30
18mm 5.71 140 1.5-3% 25.4 56.0 85 30
20mm 6.30 160mm 1.5-3% 31.3 69.0 85

30











Tensile Strength Polyurethane Round Belt / Green PU Extruded Belt 0Tensile Strength Polyurethane Round Belt / Green PU Extruded Belt 1
